Scope:
This machine is applied and industrial adhesive tape, paper, aluminum foil, copper foil, paper and plastic composite materials of various drum-shaped longitudinal section.
Features
The unit has optical tracking correction system, retractable material tension control with magnetic clutch, the host used frequency control, the cutting width can be adjusted according to requirements, accurate cutting, cutting speed, operation and easy maintenance.
Main technical parameters:
Model FQ-650
Cutting speed M / MIN 80
MM 650 Max feed width
Unwinding the largest diameter of MM 600
The maximum winding diameter of MM 450
Cutting precision MM ± 0.1
Voltage V 220
Host power KW 3
Size MM 2400 * 1700 * 1450
Weight KG 1000
